- 3.73 axle ratio
- 10.5" rear axle ring gear diameter
- 9.25" front axle ring gear diameter
- Four wheel drive
- 600-amp battery
- 136-amp alternator
- 6.3' pickup box
- 8800# GVWR
- HD front/rear shock absorbers
- Front stabilizer bar
- LT245/70R17 all-season SBR BSW tires
- Full size spare tire w/17" steel wheel, winch type carrier
- 17" x 7.5" painted steel wheels
- Pwr steering
- Pwr 4-wheel anti-lock disc brakes
- 34 gallon fuel tank
- Bright front bumper
- Front air dam
- Bright rear bumper w/step pads
- Dark gray grille
- Gray upper front fascia
- Black 6" x 9" exterior mirrors
- Tinted glass
- Variable speed intermittent windshield wipers
- Cargo lamp
- Trailer tow wiring-inc: 4-pin connector
- HD vinyl 40/20/40 split bench seat w/rear folding bench seat
- Black vinyl floor covering
- 4-spoke steering wheel
- Air conditioning
- AM/FM stereo w/cassette-inc: CD changer control, (4) speakers
- Day/night rearview mirror
- Passenger assist handle
- Rear underseat compartment storage
- Driver/front passenger "Next Generation" airbags
- Pwr 4-wheel anti-lock disc brakes
- Front shoulder belt height adjusters
- Dual note horn
5.7L (350) SMPI V8 HEMI "MAGNUM" ENGINE
- electronically controlled throttle (STD)
- 17" x 7.5" Painted Styled Steel Wheels
- 3.73 Axle Ratio
- 4 Speakers
- 4-Wheel Disc Brakes
- ABS brakes
- Air Close Out Front Panel
- Air Conditioning
- AM/FM Cassette w/Changer Control
- AM/FM radio
- Bumpers: chrome
- Cassette
- Driver door bin
- Dual front impact airbags
- Electronically Controlled Throttle
- Front anti-roll bar
- Front beverage holders
- Front Center Armrest w/Storage
- HD Vinyl 40/20/40 Split Bench Seat
- Next Generation Engine Controller
- Passenger door bin
- Power steering
- Rear step bumper
- Speed-Sensitive Wipers
- Tachometer
- Variably intermittent wipers
- Voltmeter
- Cold Cranking Amps @ 0° F (Primary): 600
- Maximum Alternator Capacity (amps): 136
- Maximum Alternator Watts: 1904
- Total Cooling System Capacity (qts): 18
- Gross Axle Wt Rating - Front (lbs): 5200
- Gross Axle Wt Rating - Rear (lbs): 6000
- Curb Weight - Front (lbs): 3358
- Curb Weight - Rear (lbs): 2669
- Gross Vehicle Weight Rating Cap (lbs): 8800
- Gross Combined Wt Rating (lbs): 15000
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 12000
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
- Suspension Type - Front: Coil
- Suspension Type - Rear: Leaf
- Axle Type - Front: Hypoid
- Axle Type - Rear: Full-floating
- Axle Capacity - Front (lbs): 4000
- Axle Capacity - Rear (lbs): 6200
- Axle Ratio (:1) - Front: 3.73
- Axle Ratio (:1) - Rear: 3.73
- Shock Absorber Diameter - Front (mm): - TBD -
- Shock Absorber Diameter - Rear (mm): - TBD -
- Stabilizer Bar Diameter - Front (in): - TBD -
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 13.9 x 1.26
- Rear Brake Rotor Diam x Thickness (in): 13.9 x 1.18
- Front Tire Size: LT265/70R17
- Rear Tire Size: LT265/70R17
- Spare Tire Size: LT265/70R17
- Front Tire Capacity (lbs): 2835
- Rear Tire Capacity (lbs): 3195
- Spare Tire Capacity (lbs): 3195
- Revolutions/Mile @ 45 mph - Front: 657
- Revolutions/Mile @ 45 mph - Rear: 657
- Revolutions/Mile @ 45 mph - Spare: 657
- Front Wheel Size (in): 17 x 7.5
- Rear Wheel Size (in): 17 x 7.5
- Spare Wheel Size (in): 17 x 7.5
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: Steel
- Steering Type: Pwr Rack & Pinion
- Steering Ratio (:1), On Center: 13.4
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb (ft): 45.1
- Turning Diameter - Wall to Wall (ft): - TBD -
- Fuel Tank Capacity, Approx (gal): 34
- Fuel Tank Location: Inboard Frame Rails
- Wheelbase (in): 140.0
- Length, Overall w/o rear bumper (in): 229.7
- Width, Max w/o mirrors (in): 79.9
- Height, Overall (in): 78.5
- Overhang, Front (in): 39.4
- Overhang, Rear w/o bumper (in): - TBD -
- Front Bumper to Back of Cab (in): 143.0
- Cab to Axle (in): 36.9
- Cab to End of Frame (in): - TBD -
- Ground to Top of Load Floor (in): 36.1
- Ground to Top of Frame (in): - TBD -
- Frame Width, Rear (in): - TBD -
- Ground Clearance, Front (in): 9.3
- Ground Clearance, Rear (in): 7.9
- Cargo Box Length @ Floor (in): 75.9
- Cargo Box Width @ Top, Rear (in): - TBD -
- Cargo Box Width @ Floor (in): 66.4
- Cargo Box Width @ Wheelhousings (in): 51.0
- Cargo Box (Area) Height (in): 20.2
- Tailgate Width (in): 63.5
- Cargo Volume (ft³): 57.7
- Passenger Capacity: 6
- Front Head Room (in): 40.8
- Front Leg Room (in): 41.0
- Front Shoulder Room (in): 67.0
- Front Hip Room (in): 65.1
- Second Head Room (in): 40.0
- Second Leg Room (in): 36.4
- Second Shoulder Room (in): 66.7
- Second Hip Room (in): 64.6
- Vehicle Name: Dodge Ram 2500
- Body Style: Quad Cab 6.3' Box
- Body Code: 140.5" WB
