- 2-speed transfer case
- 3.73 axle ratio
- Four wheel drive
- Manual locking front hubs
- 72 amp/hr (750 CCA) maintenance-free battery
- 130 amp alternator
- Trailer tow pkg-inc: 7/4-pin trailer combination connector, trailer brake wiring kit, trailer tow guide
- 156" WB
- 6-3/4' pickup box w/tie-down hooks & partitionable/stackable storage
- (2) front tow hooks
- 11,200# GVWR (4700 front/8250 rear), springs (4700 front/8250 rear), axles (5200 front/9750 rear)
- Mono-beam front axle
- Front/rear stabilizer bar
- Auxiliary rear springs *Activated when carrying heavy loads*
- HD gas shock absorbers
- (7) LT235/85R16E all-season BSW tires
- (7) 16" x 6.0" 8-hole argent styled steel wheels
- Full-size spare tire w/steel wheel, lock, underframe crank carrier
- 2-ton mechanical jack
- Pwr steering
- Pwr 4-wheel disc brakes
- 4-wheel anti-lock braking system (ABS)
- 29 gallon fuel tank
- Front/rear license plate bracket
- Argent painted front/rear step bumper
- Black box-rail/tailgate top edge moldings
- Valance air dam
- Argent grille
- Sealed beam halogen headlamps
- Pickup box/cargo light
- Roof/rear fender/below tailgate clearance lights
- Black fold-away manual mirrors
- Solar tinted glass
- Interval wipers
- Black door handles
- Tailgate w/black handle
- HD knitted vinyl reclining front bench seat w/outboard headrests
- Forward-folding rear bench seat
- Black vinyl full-floor covering
- Color-keyed scuff plates
- Black vinyl steering wheel
- Instrumentation-inc: tachometer, trip odometer, voltmeter, oil pressure/ coolant temp/fuel gauges, indicator lights
- Belt Minder seatbelt-not-buckled chime & flashing warning light
- Inside hood release
- (4) air registers w/positive shut-off
- Electronic AM/FM stereo radio-inc: digital clock, (2) speakers
- Color-keyed instrument panel-inc: dual cupholders, glove box, ashtray, cigar lighter, storage bin, trash bag hook
- Auxiliary pwr point
- Color-keyed molded door trim panel-inc: hard armrest, grab handle, reflector
- 11.5" day/night mirror
- Color-keyed molded cloth headliner
- Driver & front passenger grab handles
- Front passenger-side roof ride handle
- Rear seating roof ride handles
- Dual color-keyed cloth sunvisors-inc: driver-side map strap, passenger-side mirror insert
- Dual color-keyed coat hooks
- Dual dome lamps w/time delay off
- Dual map lights
- Grey fabric back panel cover
- 4-wheel anti-lock braking system (ABS)
- Driver & front passenger airbags
- Color-keyed safety belts w/front seat adjustable D-rings
- Front/rear child seat tethers (on all seats)
- Dual-note horn
6.0L (364) DI V8 TURBO-DIESEL "POWER STROKE" ENGINE
- dual 78 amp/hr batteries
- engine block heater
- 3.73 Axle Ratio
- GVWR: 11,200 lb Payload Package (#1)
- Integrated Molded Black Cab Steps
- Speed Control w/Tilt Steering Wheel
- Sliding Rear Window
- Trailer Tow Package
- Chrome Rear Step Bumper
- 4-Wheel ABS Brakes
- Driver & Passenger Airbag
- Front Tow Hooks
- Dual rear wheels
- Front beverage holders
- Variably intermittent wipers
- Rear step bumper
- Rear reading lights
- Rear anti-roll bar
- Power steering
- Passenger vanity mirror
- Front reading lights
- Front anti-roll bar
- Dual front impact airbags
- AM/FM radio
- ABS brakes
- Voltmeter
- Tachometer
- Air Conditioning
- 4-Wheel Disc Brakes
- Cold Cranking Amps @ 0° F (Primary): 750
- Cold Cranking Amps @ 0° F (2nd): 750
- Maximum Alternator Capacity (amps): 130
- Total Cooling System Capacity (qts): - TBD -
- Total Cooling System Capacity (qts): 26.0
- Gross Axle Wt Rating - Front (lbs): - TBD -
- Gross Axle Wt Rating - Front (lbs): 4000
- Gross Axle Wt Rating - Rear (lbs): 8250
- Curb Weight - Front (lbs): 3697
- Curb Weight - Rear (lbs): 2689
- Gross Vehicle Weight Rating Cap (lbs): 11,200
- Gross Combined Wt Rating (lbs): - TBD -
- Gross Combined Wt Rating (lbs): 16,500
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 12400
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 9400
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 1240
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 940
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 12400
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 9400
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1240
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 940
- Suspension Type - Front: Single Leaf
- Suspension Type - Rear: Multi-Leaf
- Spring Capacity - Front (lbs): - TBD -
- Spring Capacity - Front (lbs): 4000
- Spring Capacity - Rear (lbs): 8250
- Axle Type - Front: Dana Monobeam
- Axle Type - Rear: Ford Full-Floating
- Axle Capacity - Front (lbs): 5200
- Axle Capacity - Rear (lbs): 9750
- Axle Ratio (:1) - Front: 3.73
- Axle Ratio (:1) - Rear: 3.73
- Shock Absorber Diameter - Front (mm): 35
- Shock Absorber Diameter - Rear (mm): 35
- Stabilizer Bar Diameter - Front (in): - TBD -
- Stabilizer Bar Diameter - Rear (in): - TBD -
- Brake Type: Power
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 13.03 x - TBD -
- Rear Brake Rotor Diam x Thickness (in): 12.83 x - TBD -
- Front Tire Order Code: T35
- Rear Tire Order Code: T35
- Front Tire Size: LT235/85R16E
- Rear Tire Size: LT235/85R16E
- Spare Tire Size: LT235/85R16E
- Front Tire Capacity (lbs): 2778
- Rear Tire Capacity (lbs): 2778
- Spare Tire Capacity (lbs): 2778
- Revolutions/Mile @ 45 mph - Front: 655
- Revolutions/Mile @ 45 mph - Rear: 655
- Revolutions/Mile @ 45 mph - Spare: 655
- Front Wheel Size (in): 16 x 6.0
- Rear Wheel Size (in): 16 x 6.0
- Spare Wheel Size (in): 16 x 6.0
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: Steel
- Steering Type: Power
- Steering Ratio (:1), On Center: 17.0
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb (ft): 56.7
- Turning Diameter - Wall to Wall (ft): 59.3
- Fuel Tank Capacity, Approx (gal): 29
- Fuel Tank Location: Midship
- Wheelbase (in): 156.2
- Length, Overall w/o rear bumper (in): 241.4
- Width, Max w/o mirrors (in): 95.5
- Height, Overall (in): 81.0
- Overhang, Front (in): 37.4
- Overhang, Rear w/o bumper (in): 47.8
- Front Bumper to Back of Cab (in): 153.6
- Cab to Axle (in): 40.0
- Cab to End of Frame (in): - TBD -
- Ground to Top of Load Floor (in): 38.2
- Ground to Top of Frame (in): - TBD -
- Frame Width, Rear (in): - TBD -
- Ground Clearance, Front (in): - TBD -
- Ground Clearance, Rear (in): - TBD -
- Cargo Box Length @ Floor (in): 82.4
- Cargo Box Width @ Top, Rear (in): 64.6
- Cargo Box Width @ Floor (in): - TBD -
- Cargo Box Width @ Wheelhousings (in): 50.9
- Cargo Box (Area) Height (in): 20.0
- Tailgate Width (in): 65.0
- Cargo Volume (ft³): 64.7
- Passenger Capacity: 6
- Front Head Room (in): 41.4
- Front Leg Room (in): 40.7
- Front Shoulder Room (in): 68.0
- Front Hip Room (in): 67.4
- Second Head Room (in): 41.0
- Second Leg Room (in): 42.5
- Second Shoulder Room (in): 68.0
- Second Hip Room (in): 67.3
- Vehicle Name: Ford Super Duty F-350 DRW
- Body Style: Crew Cab 6-3/4'
- Body Code: 156" WB
